Nirav Patel

Add TQFN-32-1EP_3x6mm_P0.4mm_EP1.25x3.5mm

3

Add TQFN-32-1EP_3x6mm_P0.4mm_EP1.25x3.5mm from https://www.diodes.com/assets/Datasheets/PI3DPX1203B.pdf

Create WQFN-20-1EP_3x3mm_P0.4mm_EP1.8x1.8mm_ThermalVias

5

Footprint from https://www.ti.com/lit/ds/symlink/tpd6s300a.pdf#page=32 Note that this is also called S-PWQFN-N20 by TI, but there is an existing footprint for that in the library that doesn't match TI's drawing.  ---...

Create TQFN-32-1EP_3x6mm_P0.4mm_EP1.25x3.5mm

3

Create TQFN-32-1EP_3x6mm_P0.4mm_EP1.25x3.5mm using footprint generator. From https://www.diodes.com/assets/Datasheets/PI3DPX1203B.pdf The Diodes footprint name is ZL32 and the drawing is at https://www.diodes.com/assets/Package-Files/ZL32.pdf though it's an older revision than in the PI3DPX1203B datasheet. ...

Create QFN-10_1.8x1.4mm_P0.4mm

2

Create QFN-10_1.8x1.4mm_P0.4mm used in STG3684AU, called QFN10L by ST. https://www.st.com/resource/en/datasheet/stg3684a.pdf  --- All contributions to the kicad library must follow the [KiCad library convention](http://kicad-pcb.org/libraries/klc/) Thanks for creating a pull request...

Create TPD6S300A

6

Create TI https://www.ti.com/lit/ds/symlink/tpd6s300a.pdf  Uses the footprint at https://github.com/KiCad/kicad-footprints/pull/1992 --- All contributions to the kicad library must follow the [KiCad library convention](http://kicad-pcb.org/libraries/klc/) Thanks for creating a pull request to contribute...

Add Interface_DisplayPort lib with PI3DPX1203BZLEX symbol

3

Create an Interface_DisplayPort library starting with a symbol for Diodes Inc PI3DPX1203BZLEX https://www.diodes.com/assets/Datasheets/PI3DPX1203B.pdf The associated footprint is in https://github.com/KiCad/kicad-footprints/pull/1979 Note that the VDD pins are not stacked because Diodes recommends...

Create STG3684AU

2

Create STG3684AU Low voltage 0.5Ω max dual SPDT switch, QFN10L Footprint in https://github.com/KiCad/kicad-footprints/pull/1981 https://www.st.com/resource/en/datasheet/stg3684a.pdf  --- All contributions to the kicad library must follow the [KiCad library convention](http://kicad-pcb.org/libraries/klc/) Thanks for...

Create TPS22976

3

http://www.ti.com/lit/ds/symlink/tps22976.pdf Note that VIN and VOUT are passive because they can actually be connected backwards for use in reverse current blocking. *Replace this line with your commit message! Please provide...
