Sparse Surface Constraints for Combining Physics-based Elasticity Simulation and Correspondence-Free Object Reconstruction (CVPR 2020)

Sebastian Weiss, Robert Maier, Daniel Cremers, Ruediger Westermann, Nils Thuerey Technical University of Munich

License

This software, excluding third party libraries, is distributed under the MIT open source license. See LICENSE for details.

Resources

• Project page
• Preprint (PDF)

Citation

If you find this source code or the paper useful in your research, please cite our work as follows:

@inproceedings{weiss2020correspondence,
    title={Correspondence-Free Material Reconstruction using Sparse Surface Constraints},
    author={Weiss, S. and Maier, R. and Cremers, D. and Westermann, R. and Thuerey, N.},
    booktitle={Conference on Computer Vision and Pattern Recognition (CVPR)},
    year={2020},
    month={June},
    address={Seattle, WA, USA}
}

Source Code

Reference implementation of "Sparse Surface Constraints for Combining Physics-based Elasticity Simulation and Correspondence-Free Object Reconstruction"

See the Releases-page for datasets, binaries and benchmark results

Projects in the solution

• Libraries:
  • ActionReconstructionLib: 2D simulation code, no CUDA dependency
  • ActionReconstruction3DLib: 3D simulation code
• Main Apps, single source files that plug the calls exposed by the libraries above together with a simple GUI:
  • SoftBodyFEMApp: simple 2D forward simulation (no CUDA)
  • InverseSoftBodyApp: Forward and Inverse simulation in the 2D case (no CUDA)
  • SoftBody3DApp: Forward and inverse simulation for synthetic cases, 3D
  • MainApp: Inverse simulation for inputs from external 3D scans, 3D
• Remaining projects are benchmarks (projects ending in 'Benchmarks') or tests (ending in 'Test')

HowTo simulate in 2D

(Based on SoftBodyFEM2DApp.cpp in the project SoftBodyFEMApp)

Assume all includes and namespaces are imported.

Initialize grid solver. There are utilities to create grids filled with a rect or a torus. For example:

SoftBodyGrid2D gridSolver = SoftBodyGrid2D::CreateTorus(
    torusOuterRadius, torusInnerRadius, gridResolution,
    enableDirichletBoundaries, dirichletForce, neumannForce);

If you want the inverse simulation, initialize the results:

SoftBody2DResults results;
results.initGridReference(gridSolver);

Perform a forward step. This is performed in the background thread of ar::BackgroundWorker.

//Set simulation parameters
gridSolver.set....
//Pass them to the results for a ground truth and for the values that are not reconsructed
results.settings_ = gridSolver.getSettings();
//solve it (of of the following two)
gridSolver.solveStaticSolution(worker);
gridSolver.solveDynamicSolution(worker);
//save result as observation for the reconstruction
results.gridResultsSdf_.push_back(gridSolver.getSdfSolution());
results.gridResultsUxy_.push_back(gridSolver.getUSolution());

Solve the inverse problem:

//create the solver
InverseProblem_Adjoint_Dynamic solver;
//set parameters, including starting values and reconstructed parameters
solver.setGridUsePartialObservation(true);
...
//set recorded input
solver.setInput(results);
//solve with callback
solver.solveGrid(numTimesteps, worker, [this](const InverseProblemOutput& intermediateSolution)
{
	//whatever you want
});

HowTo simulate in 3D

(Based on SoftBody3DApp.cu)

Load input from an SDF file. See the other SoftBodyGrid3D::create... methods for alternatives.

SoftBodySimulation3D::InputSdfSettings inputSettings = {...};
SoftBodyGrid3D::Input input = SoftBodyGrid3D::createFromFile(inputSettings);

Create the simulation

SoftBodySimulation3D::Settings settings = {...}; //all simulation parameters
SoftBodyGrid3D simulation(input);
simulation.setSettings(settings);

If you want the inverse simulation, initialize the results:

SimulationResults3DPtr results = std::make_shared<ar3d::SimulationResults3D>();
results->input_ = simulation.getInput();
results->settings_ = simulation.getSettings();

Simulate a single forward step, performed withing a task of BackgroundWorker2.

simulation.solve(true, true);
//capture state to use them as observations
results->states_.push_back(simulation.getState().deepClone());

Create cost function:

ar3d::CostFunctionPtr costFunction = std::make_shared<ar3d::CostFunctionPartialObservations>(results, &costFunctionPartialObservations);
costFunction->preprocess(&worker);

Solve the inverse problem:

//specify a ton of settings: optimizer, step sizes, initial values, which parameters to optimize, ...
AdjointSolver::Settings settings;
...
//create the solver
AdjointSolver solver(results, settings, costFunction);
//solve with callback
AdjointSolver::Callback_t callback = [&](const ar3d::SoftBodySimulation3D::Settings& var, const ar3d::SoftBodySimulation3D::Settings& gradient, ar3d::real cost)
{
	//whatever you want
};
solver.solve(callback, &worker);

UI

Graphical output was done with Cinder. For 2D, have a look at GridVisualization.h in ActionReconstructionLib For 3D, have a look at VolumeVisulization.h in ActionReconstruction3DLib

Contact

If you have any questions, feel free to contact me: Sebastian Weiss, [email protected]
