layer shell: attaching null buffer does not behave as expected
Expected behavior
Attaching a null buffer to a layer surface unmaps it.
Unmapping a layer_surface means that the surface cannot be shown by the compositor until it is explicitly mapped again. The layer_surface returns to the state it had right after layer_shell.get_layer_surface. The client can re-map the surface by performing a commit without any buffer attached, waiting for a configure event and handling it as usual.
Actual behavior
After attaching null buffer the surface disappears, but the "exclusive zone" is not shifted. Reattaching a non-null buffer does not trigger a configure event.
does it work on sway? I'd imagine something like this should be handled by wlr
Tested sway, it is partially broken.
Reattaching a buffer does trigger a configure event, but the exclusive zone isn't cleared.
Reattaching a buffer does trigger a configure event
But only if I resize sway's window (I run it inside another wayland session). So I suppose it is just as broken.
For context: I implemented a hide/show feature in my status bar by attaching null buffer and it worked fine in river.
wlroots. Wat
can you link me your test client
https://github.com/MaxVerevkin/i3bar-river/tree/hyprland
No config. pkill -SIGUSR1 i3bar-river to show hide.
I've just tried 0.41.0, it is still a thing. Worse yet, hypland crashes. Steps: hide the bar (it is hidden but the exclusive zone is not reclaimed), show the bar (nothing happens), open a terminal (crash). I've run a packaged version and the backtrace is almost useless, but here it is:
(gdb) bt full
#0 0x00007ecce0c7be44 in ??? () at /usr/lib/libc.so.6
#1 0x00007ecce0c23a30 in raise () at /usr/lib/libc.so.6
#2 0x00007ecce0c0b4c3 in abort () at /usr/lib/libc.so.6
#3 0x0000557f0090cab7 in handleUnrecoverableSignal(int) ()
#4 0x00007ecce0c23ae0 in <signal handler called> () at /usr/lib/libc.so.6
#5 0x0000557f0092affe in ??? ()
#6 0x0000557f009a5035 in CLayerSurface::onCommit() ()
#7 0x0000557f009a5769 in ??? ()
#8 0x0000557f009f2b6f in CSignalListener::emit(std::any) ()
#9 0x0000557f009f2ed1 in CSignal::emit(std::any) ()
#10 0x0000557f00ab21ce in ??? ()
#11 0x0000557f009f2b6f in CSignalListener::emit(std::any) ()
#12 0x0000557f009f2ed1 in CSignal::emit(std::any) ()
#13 0x0000557f00b3787b in ??? ()
#14 0x0000557f00b2eb61 in CWLSurfaceResource::bfHelper(std::vector<CSharedPointer<CWLSurfaceResource>, std::allocator<CSharedPointer<CWLSurfaceResource> > >, std::function<void (CSharedPointer<CWLSurfaceResource>, Vector2D const&, void*)>, void*) ()
#15 0x0000557f00b2f5c9 in CWLSurfaceResource::breadthfirst(std::function<void (CSharedPointer<CWLSurfaceResource>, Vector2D const&, void*)>, void*) ()
#16 0x0000557f00c2beb3 in ??? ()
#17 0x0000557f00bc9d66 in ??? ()
#18 0x00007ecce1095596 in ??? () at /usr/lib/libffi.so.8
#19 0x00007ecce109200e in ??? () at /usr/lib/libffi.so.8
#20 0x00007ecce1094bd3 in ffi_call () at /usr/lib/libffi.so.8
#21 0x00007ecce15fbe45 in ??? () at /usr/lib/libwayland-server.so.0
#22 0x00007ecce1600c42 in ??? () at /usr/lib/libwayland-server.so.0
#23 0x00007ecce15ff0a2 in wl_event_loop_dispatch () at /usr/lib/libwayland-server.so.0
#24 0x00007ecce160110f in wl_display_run () at /usr/lib/libwayland-server.so.0
#25 0x0000557f00a536b9 in CEventLoopManager::enterLoop(wl_display*, wl_event_loop*) ()
#26 0x0000557f008d0eb1 in main ()
