when trying to mark downstream tasks as failed in the UI tasks are instead cleared and reran

[tronlightracer]

Apache Airflow version

main (development)

What happened

When trying to mark downstream tasks as failed in the UI the tasks are instead cleared of any status and airflow reruns the tasks.

What you think should happen instead

When marking the tasks as either failed or success the it should set the tasks to those states. It shouldn't rerun downstream tasks if I'm setting the downstream option when marking the task as failed.

How to reproduce

Mark a task as failed with the downstream option set

Operating System

Docker (debian:buster)

Versions of Apache Airflow Providers

No response

Deployment

Other

Deployment details

happens in airflow breeze and the astro cli

Anything else

occurs everytime.

Are you willing to submit PR?

• [ ] Yes I am willing to submit a PR!

Code of Conduct

• [X] I agree to follow this project's Code of Conduct

[tirkarthi]

I guess the issue occurs that after setting state the subdags are cleared with only_failed as always True. Hence if the state being set is failed then it goes on to clear the state. So we need to make sure only_failed is False when the state being set is already failed. In addition to this the exclude_task_ids only includes the main task_id and with downstream set as True the other altered task_ids that includes downstream task ids should also be added to this list so that the state is not cleared.

I can raise a PR for this.

https://github.com/apache/airflow/blob/a801ea3927b8bf3ca154fea3774ebf2d90e74e50/airflow/models/dag.py#L1690-L1699

[tirkarthi]

Related PR for more discussion : https://github.com/apache/airflow/pull/13037

[uranusjr]

cc @yuqian90 (PR author)

[tirkarthi]

Another scenario is that when the task_1 being set to mark as failed is already in failed state and downstream task task_2 also marked as failure already. Then marking the state even with downstream as false clears the state. I have added test case for possible permutations. I have a local branch and below are the behaviors as per my proposed change.

 with DAG("test_mark_task_instance_state_failed_downstream_clear", start_date=start_date) as dag:
    task_1 = EmptyOperator(task_id="task_1")
    task_2 = EmptyOperator(task_id="task_2")
    task_3 = EmptyOperator(task_id="task_3")

    task_1 >> task_2 >> task_3

Mark task_1 as Failed with Downstream True

Task	Start state	End state
task_1	Success	Failed
task_2	Success	Failed
task_3	Success	Failed

Task	Start state	End state
task_1	Success	Failed
task_2	Success	Failed
task_3	Failed	Failed

Mark task_1 as Failed with Downstream False

Task	Start state	End state
task_1	Success	Failed
task_2	Success	Success
task_3	Failed	None

Task	Start state	End state
task_1	Failed	Failed
task_2	Success	Success
task_3	Failed	Failed

Task	Start state	End state
task_1	Success	Failed
task_2	Success	Success
task_3	Success	Success

[github-actions[bot]]

This issue has been automatically marked as stale because it has been open for 365 days without any activity. There has been several Airflow releases since last activity on this issue. Kindly asking to recheck the report against latest Airflow version and let us know if the issue is reproducible. The issue will be closed in next 30 days if no further activity occurs from the issue author.

[github-actions[bot]]

This issue has been closed because it has not received response from the issue author.
