HavokLib

HavokLib is an independent Havok packfile serialize and XML store library for C++.
In addition, it can output packfile formats into XML/Bin under any available version. This library can possibly upgrade/downgrade between versions.
Library can also store classic data for XML direct export.
Library uses wrapper for a python 3 module.
Library is compilable under Clang 10, Windowns Clang 13.0.1 and G++10.

Toolset

Toolset can be found in Toolset folder

Toolset releases

Supported formats/toolset versions

Havok 5.0.0 - 2017

It also supports both endians, both x86 and x64 platforms and files compiled for all available compilers.
For versions 2015+, there aren't any samples for unit tests. Only MSVC formats tested!
This library doesn't support loading tagfiles and never will.
Binary exporting is an experimental feature for now.

Supported classes

• hkaSkeleton: 5.0.0 - 2017
• hkRootLevelContainer: 5.0.0 - 2017
• hkaAnimationContainer: 5.0.0 - 2017
• hkaAnimation (not final): 5.0.0 - 2017
• hkaDeltaCompressedAnimation: 5.0.0 - 2010
• hkaWaveletCompressedAnimation: 5.0.0 - 2010 (/wo decompressor)
• hkaAnnotationTrack: 5.0.0 - 2017
• hkaInterleavedAnimation: 5.0.0 - 2015
• hkaAnimationBinding: 5.0.0 - 2017
• hkxEnvironment: 5.0.0 - 2014
• hkaSplineCompressedAnimation: 5.0.0 - 2017
• hkaDefaultAnimatedReferenceFrame: 5.0.0 - 2014

Supported XML classes

• hkRootLevelContainer
• hkaAnimationContainer
• hkaSkeleton
• hkaAnnotationTrack
• hkaInterleavedAnimation
• hkaAnimationBinding
• hkxEnvironment

Python wrapper classes

• hkRootLevelContainer
• hkaAnimationContainer
• hkaSkeleton
• hkxEnvironment

Binary export classes (v5 - v2014)

• hkRootLevelContainer (read-only)
• hkaAnimationContainer (read-only)
• hkaSkeleton (read-only)
• hkxEnvironment (read-only)
• hkNamedVariant
• hkaPartition

License

This library is available under GPL v3 license. (See LICENSE.md)

This library uses following libraries:

• PreCore, Copyright (c) 2016-2022 Lukas Cone
