'scl' property of 'img' disappeared

[goessner]

mec.shape.img is handing over a scl property to g2.img command. Examples using this worked some months ago.

This is needed to perform a homogenious scaling. Using b and h properties for scaling does not work, as the real dimensions of the image are not known to the user.

[klawr]

I don't know how they could have worked, since image never had a scl property, if i am not mistaken. In the old g2 there is no scl for image and at the moment i can't find any functionality which would indicate that behavior exists. We could put a scl in img which would be multiplied with b and h, but maybe wrapping an image with beg and end is more consistent.

[klawr]

I could implement a scaling property into the inversion for cartesian mode though, which should fit in quite nice.

[goessner]

It might be, that I implemented a sclproperty experimentally, which I forgot to push. But homogenious scaling is a must have in my opinion. If we use beg .. end for this as a workaround we should consequently also remove the positioning properties, which would makes no sense (performance), as in canvas, svg, etc. images can be directly positioned, rotated and scaled.

[goessner]

Scaling works now ... but the image location seems to be scaled also ...

[klawr]

Changed implementation method. Width and height of image is now just multiplied with scl property. Should behave as expected now.

[goessner]

Hmm ... scaling is gone again. Unfortunately running out of time. Please try for yourself. That Mechanism ...

    {
        "id":"4bar",
        "nodes": [
            { "id":"A0","x":100,"y":100, "base":true },
            { "id":"A","x":100,"y":150 },
            { "id":"B","x":350,"y":220 },
            { "id":"B0","x":300,"y":100, "base":true }
        ],
        "constraints": [
            { "id":"a","p1":"A0","p2":"A","len":{ "type":"const" } },
            { "id":"b","p1":"A","p2":"B","len":{ "type":"const" } },
            { "id":"c","p1":"B0","p2":"B","len":{ "type":"const" } }
        ],
        "shapes": [
            { "type":"img","uri":"../img/hand.png","p":"A0","wref":"a","w0":-1.5708,"xoff":140,"yoff":80,"scl":0.1 },
            { "type":"fix","p":"A0" },
            { "type":"img","uri":"../img/hand.png","p":"A","wref":"b","w0":-1.5708,"xoff":140,"yoff":80,"scl":0.1 },
            { "type":"img","uri":"../img/hand.png","p":"B0","wref":"c","w0":-1.5708,"xoff":140,"yoff":80,"scl":0.1 }
        ]
    }

with that image

[klawr]

I see. I should review the scaling again. But frankly i would not use scl here.

{ "type":"img","uri":"./hand.png","p":"A0","wref":"a","w0":-1.5708,"xoff":100,"b":25,"h":50 },

Seems to be good enough, but the corner of the image is hard coded to the point. Maybe we should review that behavior in mec.shape

[klawr]

I think i have identified the problem and scaling should work as intended now. Am a bit hesitant to close the issue till further testing though.
