BASE64 instaed of screen shot location in the report

[nagu4u2c]

Hi anshooarora,

Could we use BASE64 instead of the screen shot location in the report, so that there is no dependency on the location of the screen shots placed.

[anshooarora]

Its possible. Using the example here: http://dean.edwards.name/my/base64-ie.html

    "/////wAAACwAAAAADwAPAAACIISPeQHsrZ5ModrLlN48CXF8m2iQ3Y" +
    "mmKqVlRtW4MLwWACH+H09wdGltaXplZCBieSBVbGVhZCBTbWFydFNhdmVyIQAAOw==";

test.log(LogStatus.INFO, "Embedded Image: " +
    test.addScreenCapture(s));

[nagu4u2c]

Thanks anshooarora.

However when I used BASE64 in the extentreports, I'm unable to open the image after clicking on the image in the report.

When I click on the image in the report. The image does not get displayed.

Thanks in advance

[anshooarora]

Issue has been fixed since 2.40.2.

[devsh4]

This is still happening even while using screenshot location/path for version 2.41.2.

[shanmukha27]

Hi Anshooarora,

I still see this issue occurring in 2.41.0 (Latest Build - Nuget Packages). When I try to zoom into the screenshot the image doesn't gets displayed and returns an error message too.

Regards, Santosh

[rab2215]

I am currently using version 2.41.1 with base64 images, which render in the report as expected. I am evaluating version 3.0.1 and I no longer see this option. Has this feature been removed?

[shanmukha27]

My issue is fixed now with the below code:

test.Log(LogStatus.Fail, "Error Snapshot : " + test.AddBase64ScreenCapture(imgFormat));

Regards, Santosh

[danielsidler]

Hi shanmukha27. I am looking into the AddBase64ScreenCapture method and can't find much on it. What is imgFormat in this scenario? I am trying to pass the base64 as a string

[shanmukha27]

Hi Daniel,


You can refer the below code:

            string imgFormat;
            using (System.Drawing.Image image = System.Drawing.Image.FromFile(screenshotPath))
            {
                using (MemoryStream m = new MemoryStream())
                {
                    string base64String;
                    image.Save(m, image.RawFormat);
                    byte[] imageBytes = m.ToArray();
                    base64String = Convert.ToBase64String(imageBytes);
                }
            }
            test.Log(LogStatus.Fail, "Error Snapshot : " + test.AddBase64ScreenCapture(imgFormat));

Hope this helps..

Regards, Santosh

[danielsidler]

Thank you, I have it working now, and this was about the only resource I could find! I have one problem remaining. The screenshots are a bit too big, since they were taken of a whole screen. They go off of the edge of the HTML page, and shrinking them would also make the file smaller. Reducing the size by about 25% would make everything fit.

Is there any way to take a smaller base64 screenshot, or shrink the one taken? My current screenshot method and the line calling it:

public static String CaptureScreen(WebDriver driver){
     TakesScreenshot newScreen = (TakesScreenshot) driver;
     String scnShot = newScreen.getScreenshotAs(OutputType.BASE64);
}

t.addBase64ScreenShot(ComplexReportFactory.CaptureScreen(getDriver())));

[shanmukha27]

I guess you can use Bitmap to reduce the size of the screenshot. I found some stuff online hope this helps.

https://forums.asp.net/t/1702883.aspx?How+to+reduce+dimension+of+picture+taken+by+C+half+

[PePeLM]

Hello @anshooarora, I have the same problem when I click on the image in the report. The image does not get displayed. I'm on latest version 3.0.6.


Is that file too big maybe?

[taddeuz]

Hello @PePeLM / @anshooarora I have the same issue (using 3.0.6). In the lightbox, the image is displayed like the screenshot attached By PePeLm. Maybe an issue caused by the jQuery Plugin Featherlight?

[PePeLM]

@taddeuz I downgraded to v 2.41.2 and I saved as FILE and that works for me. Now I need to integrate this with TestNG listener somehow ...

[abvijay]

How the same can be achieved in JAVA? Could someone plz share the code..

[abvijay]

@anshooarora ScreenShot is available in Report but when clicked on it, it is blank.


logger.fail("details", MediaEntityBuilder.createScreenCaptureFromPath(screenshot_path).build());

[bksooraj]

Whoever is unable to see the screenshot when you click on thumbnail, can you people try opening it in Chrome browser? Even I faced same issue when I tried using IE, but same file when opened with Chrome displays correctly.

[jmatthews79]

I was able to add this to the report at test level flawlessly in C# and nunit if anyone is interest here it is:

`

        string testName = TestContext.CurrentContext.Test.Name;
        string path = TestContext.CurrentContext.TestDirectory + "\\";
        string fileName = testName + ".png";
        string extentReportImage = Path.Combine(path, fileName);

        ITakesScreenshot screenshotDriver = driver as ITakesScreenshot;
        Screenshot screenshot = screenshotDriver.GetScreenshot();
        screenshot.SaveAsFile(extentReportImage);

        string imgFormat;

        using (Image image = Image.FromFile(extentReportImage))
        {
            using (MemoryStream m = new MemoryStream())
            {
                string base64String;
                image.Save(m, image.RawFormat);
                byte[] imageBytes = m.ToArray();
                base64String = Convert.ToBase64String(imageBytes);
                imgFormat = base64String;
            }
        }

        try
        {
            test.Log(Status.Fail, "Screenshot from failed test step:", MediaEntityBuilder.CreateScreenCaptureFromBase64String(imgFormat).Build());
        }
        catch (IOException e)
        {
            Console.WriteLine("Error in the captureAndDisplayScreenShot method: " + e.Message);
        }
    `

[anshooarora]

@jmatthews79 is this feature not working at the event/log level?

[SwathiNallan]

Hi @abvijay

You can use the below code to capture screenshot, save to the specified location and embed to the report.

Reporter.addScreenCaptureFromPath(CaptureScreen(driver,"FailedScenario"));

public String CaptureScreen(WebDriver driver, String imageName) { File sourceFile = ((TakesScreenshot)driver).getScreenshotAs(OutputType.FILE); String encodedBase64 = null; FileInputStream fileInputStreamReader = null; try { fileInputStreamReader = new FileInputStream(sourceFile); byte[] bytes = new byte[(int)sourceFile.length()]; fileInputStreamReader.read(bytes); encodedBase64 = new String(Base64.encodeBase64(bytes));

        String screenShotDestination = createScreeshotFolderStructure()+"/"+
                imageName.trim().replace(" ","_") + ".png";

        File destination = new File(screenShotDestination);
        FileUtils.copyFile(sourceFile, destination);

    } catch (IOException e) {
        e.printStackTrace();
    }
}

[testergirlash]

@PePeLM, @anshooarora , I am still facing the issue, The image is displayed as thumbnail in the report. But when I zoom it, it shows something like this ,

Can anyone please enlighten?

[beedyb220]

I added base64 images to my report and they are showing up as distorted when I open them. I took the string representation of it and entered it into an online decoder and the image displays correctly. Has anyone encountered this. I included screenshots and the version I'm using.

            <dependency>
		<groupId>com.aventstack</groupId>
		<artifactId>extentreports</artifactId>
		<version>3.1.5</version>
	</dependency>

[Alaray]

@beedyb220 , try to use version 3.0.7. I had experienced the same issue and since I have rolled back from 3.1.5, it started working. But note: the image size will be large, so you should reduce it before actually embed into your report
